Monitoring

Real-time monitoring and metrics collection for WebAssembly tasks

Overview

Propeller tracks OS-level metrics for every WebAssembly task running on proplets. The system collects CPU usage, memory consumption, disk I/O, thread counts, and more with minimal performance overhead.

Propeller tracks OS-level metrics for every WebAssembly task running on proplets. The system collects CPU usage, memory consumption, disk I/O, thread counts, and more with minimal performance overhead. The Rust proplet includes built-in monitoring using the sysinfo crate for cross-platform metrics. This provides compatibility across Linux, macOS, and Windows environments.

Architecture

Each proplet monitors its running tasks independently and reports metrics to the manager via MQTT. The manager aggregates metrics from all proplets, stores historical data, and exposes REST API endpoints for querying.

Architecture

Data Flow

  1. Proplet spawns a monitoring thread for each task
  2. Thread collects process metrics at configured intervals (1-120 seconds)
  3. Metrics are published to MQTT topics:
    • Proplet-level: m/{domain}/c/{channel}/control/proplet/metrics
    • Task-level: m/{domain}/c/{channel}/control/proplet/task_metrics
  4. Manager receives and stores metrics in memory
  5. API clients query metrics via HTTP endpoints

Component Responsibilities

  • Proplet: Collects task-level process metrics using system APIs
  • Manager: Aggregates, stores, and serves metrics via REST API
  • MQTT Broker: Routes metrics between proplets and manager

Metrics

The system tracks the following process-level metrics:

MetricDescriptionUnit
CPU UsageProcess CPU time as percentage of one corePercent (0-100+)
Memory UsageProcess memory consumptionBytes
Memory PercentProcess memory as percentage of total RAMPercent (0-100)
Disk ReadCumulative bytes read from diskBytes
Disk WriteCumulative bytes written to diskBytes
UptimeProcess runtime since startSeconds
Thread CountNumber of OS threadsInteger
File DescriptorsOpen file handles (Linux/macOS)Integer

Each metric sample includes an ISO 8601 timestamp for time-series analysis.

Monitoring Profiles

Profiles define which metrics to collect, how often, and how much history to retain.

Standard

Balanced monitoring for typical tasks.

{
  "enabled": true,
  "interval": 10,
  "collect_cpu": true,
  "collect_memory": true,
  "collect_disk_io": true,
  "collect_threads": true,
  "collect_file_descriptors": true,
  "export_to_mqtt": true,
  "retain_history": true,
  "history_size": 100
}
  • Interval: 10 seconds
  • Metrics: All available
  • History: 100 samples (~16 minutes)
  • Best for: Short to medium tasks, general workloads

Minimal

Lightweight monitoring for resource-constrained devices.

{
  "enabled": true,
  "interval": 60,
  "collect_cpu": true,
  "collect_memory": true,
  "collect_disk_io": false,
  "collect_threads": false,
  "collect_file_descriptors": false,
  "export_to_mqtt": false,
  "retain_history": false,
  "history_size": 0
}
  • Interval: 60 seconds
  • Metrics: CPU and memory only
  • History: None
  • Best for: IoT devices, edge nodes, battery-powered systems

Intensive

High-frequency monitoring for debugging and profiling.

{
  "enabled": true,
  "interval": 1,
  "collect_cpu": true,
  "collect_memory": true,
  "collect_disk_io": true,
  "collect_threads": true,
  "collect_file_descriptors": true,
  "export_to_mqtt": true,
  "retain_history": true,
  "history_size": 1000
}
  • Interval: 1 second
  • Metrics: All available
  • History: 1000 samples (~16 minutes)
  • Best for: Performance troubleshooting, memory leak detection, development

Batch processing

Optimized for long-running data processing tasks.

{
  "enabled": true,
  "interval": 30,
  "collect_cpu": true,
  "collect_memory": true,
  "collect_disk_io": true,
  "collect_threads": false,
  "collect_file_descriptors": false,
  "export_to_mqtt": true,
  "retain_history": true,
  "history_size": 200
}
  • Interval: 30 seconds
  • Metrics: CPU, memory, disk I/O
  • History: 200 samples (~100 minutes)
  • Best for: ETL pipelines, batch jobs, data transformations

Long-running daemon

Low-frequency monitoring for background services.

{
  "enabled": true,
  "interval": 120,
  "collect_cpu": true,
  "collect_memory": true,
  "collect_disk_io": true,
  "collect_threads": true,
  "collect_file_descriptors": true,
  "export_to_mqtt": true,
  "retain_history": true,
  "history_size": 500
}
  • Interval: 120 seconds
  • Metrics: All available
  • History: 500 samples (~16 hours)
  • Best for: Background daemons, always-on services, message processors

Automatic selection

If no profile is specified, Propeller automatically selects an appropriate profile:

  • Non-daemon tasks: Standard profile (10s intervals)
  • Daemon tasks: Long-running daemon profile (120s intervals)

Configuration

Global Settings

Control monitoring behavior using environment variables.

Proplet environment variables:

export PROPLET_ENABLE_MONITORING=true  # Enable/disable monitoring (default: true)

This setting applies to all tasks unless overridden by per-task configuration.

Per-Task Configuration

Specify a monitoring profile in your task payload to override global settings.

Example task with custom monitoring:

{
  "id": "550e8400-e29b-41d4-a716-446655440001",
  "name": "compute",
  "image_url": "docker.io/myorg/compute:v1",
  "inputs": [10, 20],
  "daemon": false,
  "monitoring_profile": {
    "enabled": true,
    "interval": 5,
    "collect_cpu": true,
    "collect_memory": true,
    "collect_disk_io": true,
    "collect_threads": true,
    "collect_file_descriptors": true,
    "export_to_mqtt": true,
    "retain_history": true,
    "history_size": 200
  }
}

If no profile is specified, Propeller uses automatic selection based on the task type.

Examples

Standard Monitoring

curl -X POST "http://localhost:7070/tasks" \
-H "Content-Type: application/json" \
-d '{
  "name": "compute",
  "image_url": "docker.io/myorg/compute:v1",
  "inputs": [10, 20],
  "daemon": false
}'

The task uses the standard profile with 10-second metric intervals.

High-Frequency Debugging

curl -X POST "http://localhost:7070/tasks" \
-H "Content-Type: application/json" \
-d '{
  "name": "debug_task",
  "image_url": "docker.io/myorg/app:debug",
  "inputs": [],
  "monitoring_profile": {
    "enabled": true,
    "interval": 1,
    "collect_cpu": true,
    "collect_memory": true,
    "collect_disk_io": true,
    "collect_threads": true,
    "collect_file_descriptors": true,
    "export_to_mqtt": true,
    "retain_history": true,
    "history_size": 1000
  }
}'

Metrics are collected every second with 1000-sample history retention.

Minimal Overhead

curl -X POST "http://localhost:7070/tasks" \
-H "Content-Type: application/json" \
-d '{
  "name": "lightweight_task",
  "image_url": "docker.io/myorg/light:v1",
  "monitoring_profile": {
    "enabled": true,
    "interval": 60,
    "collect_cpu": true,
    "collect_memory": true,
    "collect_disk_io": false,
    "collect_threads": false,
    "collect_file_descriptors": false,
    "export_to_mqtt": false,
    "retain_history": false,
    "history_size": 0
  }
}'

Only CPU and memory are collected every 60 seconds with no MQTT export.

Batch Processing

curl -X POST "http://localhost:7070/tasks" \
-H "Content-Type: application/json" \
-d '{
  "name": "process_batch",
  "image_url": "docker.io/myorg/batch:v1",
  "inputs": [1000],
  "env": {
    "BATCH_SIZE": "1000",
    "WORKERS": "4"
  },
  "monitoring_profile": {
    "enabled": true,
    "interval": 30,
    "collect_cpu": true,
    "collect_memory": true,
    "collect_disk_io": true,
    "collect_threads": false,
    "collect_file_descriptors": false,
    "export_to_mqtt": true,
    "retain_history": true,
    "history_size": 200
  }
}'

Metrics focus on CPU, memory, and disk I/O with 30-second intervals.

Metrics Export

MQTT Topics

Topic pattern:

m/{domain_id}/c/{channel_id}/metrics/proplet

All proplets publish to this topic regardless of implementation (Go or Rust).

Message Format

{
  "task_id": "550e8400-e29b-41d4-a716-446655440001",
  "proplet_id": "7c9e6679-7425-40de-944b-e07fc1f90ae7",
  "metrics": {
    "cpu_percent": 23.5,
    "memory_bytes": 52428800,
    "memory_percent": 1.2,
    "disk_read_bytes": 1048576,
    "disk_write_bytes": 524288,
    "uptime_seconds": 45,
    "thread_count": 2,
    "file_descriptor_count": 8
  },
  "aggregated": {
    "avg_cpu_usage": 38.2,
    "max_cpu_usage": 65.0,
    "avg_memory_usage": 62914560,
    "max_memory_usage": 71303168,
    "total_disk_read": 2097152,
    "total_disk_write": 1048576,
    "sample_count": 24
  },
  "timestamp": "2025-01-15T10:35:22.123456Z"
}

The aggregated field is only present when retain_history: true in the monitoring profile.

Subscribing to Metrics

Subscribe to specific domain/channel:

mosquitto_sub -h localhost -p 1883 \
  -t "m/domain-123/c/channel-456/metrics/proplet" -v

Subscribe to all metrics:

mosquitto_sub -h localhost -p 1883 \
  -t "m/+/c/+/metrics/#" -v

API Endpoints

Get task metrics:

curl "http://localhost:7070/tasks/{task_id}/metrics?offset=0&limit=100"

Get proplet metrics:

curl "http://localhost:7070/proplets/{proplet_id}/metrics?offset=0&limit=100"

Response includes paginated metrics with aggregated statistics.

Platform Support

Linux

MetricMethod
CPU/proc/[pid]/stat
Memory/proc/[pid]/status
Disk I/O/proc/[pid]/io
Threads/proc/[pid]/task
File descriptors/proc/[pid]/fd

All metrics are available with high accuracy.

macOS

Full metric support using system APIs.

MetricMethod
CPUSystem calls
MemorySystem APIs
Disk I/OSystem counters
ThreadsSystem APIs
File descriptorslsof or system calls

Performance is comparable to Linux with all metrics available.

Windows

Limited metric support due to platform constraints.

MetricSupport
CPUFull
MemoryFull
Disk I/OFull
ThreadsLimited (may report 1)
File descriptorsNot supported (always 0)

Consider running on Linux/macOS for full observability.

Integration with External Systems

Prometheus

Install mqtt2prometheus:

docker run -d \
  --name mqtt2prometheus \
  -p 9641:9641 \
  hikhvar/mqtt2prometheus:latest

Configure Prometheus scraping:

scrape_configs:
  - job_name: "propeller"
    static_configs:
      - targets: ["mqtt2prometheus:9641"]

Metrics become queryable in PromQL for alerting and dashboards.

Grafana

Build dashboards using Prometheus or MQTT datasource.

Recommended panels:

  • CPU usage timeline (line chart)
  • Memory consumption (area chart)
  • Disk I/O throughput (stacked area)
  • Thread count (gauge)
  • Per-task comparison (bar chart)

Import metrics from Prometheus or connect directly to MQTT broker.

Performance Overhead

ProfileCPU OverheadMemory Overhead
Minimal< 0.1%~1 MB
Standard< 0.5%~2 MB
Intensive< 2%~5 MB

Memory usage scales linearly with history retention:

  • No history: ~1 MB
  • 100 samples: ~2 MB
  • 1000 samples: ~5 MB

CPU overhead primarily comes from system call frequency.

Troubleshooting

No Metrics Published

Check global monitoring setting:

echo $PROPLET_ENABLE_MONITORING

Verify MQTT connectivity:

mosquitto_sub -h localhost -p 1883 -t "m/+/c/+/metrics/#" -v

Ensure task has monitoring enabled:

{
  "monitoring_profile": {
    "enabled": true,
    "export_to_mqtt": true
  }
}

Review proplet logs:

docker logs propeller-proplet

High CPU Overhead

Reduce collection frequency and disable unused metrics.

{
  "monitoring_profile": {
    "interval": 60,
    "collect_disk_io": false,
    "collect_threads": false,
    "retain_history": false
  }
}

High Memory Usage

Disable history retention or reduce sample count.

{
  "monitoring_profile": {
    "retain_history": false,
    "history_size": 0
  }
}

Missing Metrics on Windows

Windows has limited support for threads and file descriptors. Use Linux or macOS for full metric availability.

Inaccurate CPU Measurements

CPU percentage is calculated over the collection interval. Use intervals ≥ 1 second for stable readings. CPU-bound processes show more accurate metrics than I/O-bound processes.

API Reference

Monitoring Profile Schema

{
  "enabled": true,
  "interval": 10,
  "collect_cpu": true,
  "collect_memory": true,
  "collect_disk_io": true,
  "collect_threads": true,
  "collect_file_descriptors": true,
  "export_to_mqtt": true,
  "retain_history": true,
  "history_size": 100
}
FieldTypeDescription
enabledbooleanEnable/disable monitoring
intervalintegerCollection interval (seconds)
collect_cpubooleanTrack CPU usage
collect_memorybooleanTrack memory usage
collect_disk_iobooleanTrack disk I/O
collect_threadsbooleanTrack thread count
collect_file_descriptorsbooleanTrack file descriptors
export_to_mqttbooleanPublish to MQTT
retain_historybooleanKeep historical samples
history_sizeintegerNumber of samples to retain

Metrics Schema

{
  "cpu_percent": 23.5,
  "memory_bytes": 52428800,
  "memory_percent": 1.2,
  "disk_read_bytes": 1048576,
  "disk_write_bytes": 524288,
  "uptime_seconds": 45,
  "thread_count": 2,
  "file_descriptor_count": 8
}
FieldTypeDescription
cpu_percentfloatCPU usage (0-100+ per core)
memory_bytesintegerMemory usage in bytes
memory_percentfloatMemory as % of total RAM
disk_read_bytesintegerCumulative bytes read
disk_write_bytesintegerCumulative bytes written
uptime_secondsintegerProcess runtime
thread_countintegerOS thread count
file_descriptor_countintegerOpen file handles

Aggregated Metrics Schema

{
  "avg_cpu_usage": 38.2,
  "max_cpu_usage": 65.0,
  "avg_memory_usage": 62914560,
  "max_memory_usage": 71303168,
  "total_disk_read": 2097152,
  "total_disk_write": 1048576,
  "sample_count": 24
}
FieldTypeDescription
avg_cpu_usagefloatAverage CPU over history
max_cpu_usagefloatPeak CPU over history
avg_memory_usageintegerAverage memory (bytes)
max_memory_usageintegerPeak memory (bytes)
total_disk_readintegerTotal bytes read
total_disk_writeintegerTotal bytes written
sample_countintegerNumber of samples

Getting Started

Start Infrastructure

cd propeller
make start-supermq

Enable Monitoring

export PROPLET_ENABLE_MONITORING=true
docker restart propeller-proplet

Subscribe to Metrics

mosquitto_sub -h localhost -p 1883 -t "m/+/c/+/metrics/#" -v

Create Task

curl -X POST "http://localhost:7070/tasks" \
-H "Content-Type: application/json" \
-d '{
  "name": "compute",
  "image_url": "docker.io/myorg/compute:v1",
  "inputs": [10, 20]
}'

Start the task:

curl -X POST "http://localhost:7070/tasks/{task_id}/start"

Metrics will appear in the MQTT subscriber terminal every 10 seconds.

Manager

Central service for task management and proplet coordination in Propeller

Proplet

Worker nodes that execute WebAssembly tasks in the Propeller system

On this page

OverviewArchitectureData FlowComponent ResponsibilitiesMetricsMonitoring ProfilesStandardMinimalIntensiveBatch processingLong-running daemonAutomatic selectionConfigurationGlobal SettingsPer-Task ConfigurationExamplesStandard MonitoringHigh-Frequency DebuggingMinimal OverheadBatch ProcessingMetrics ExportMQTT TopicsMessage FormatSubscribing to MetricsAPI EndpointsPlatform SupportLinuxmacOSWindowsIntegration with External SystemsPrometheusGrafanaPerformance OverheadTroubleshootingNo Metrics PublishedHigh CPU OverheadHigh Memory UsageMissing Metrics on WindowsInaccurate CPU MeasurementsAPI ReferenceMonitoring Profile SchemaMetrics SchemaAggregated Metrics SchemaGetting StartedStart InfrastructureEnable MonitoringSubscribe to MetricsCreate Task
